At power scope of 40kW~500kW, Ettes Cummins series biogas power generator & CHP (combined hest and power) units are driven by engines of 4B3.9, 6B5.9, 6C8.3, NT855, KT19 and KT38 etc, with merits of high reliable, quick installation, easy operation and low maintenance cost. Besides standard package of biogas electric generator, client’s special requirements can be tailored like CHP, CCHP, trigeneration, ATS, parallel operation system, remote monitor & Control, modularized soundproof & weatherproof container.



Model List of Cummins Biogas Gensets & CHPs (50Hz, 1500rpm)
Model	Elec. Power (kWe)	Heat Output (kWt)	Engine  Model	Engine Max Power (kW)	Cyls. & Type	Dspl.(L)	Elec. Eff.	Heat Eff.	Total Eff.	PDF D/L
EC-24B5	24	35	4BTA3.9-G	37	4.L	3.9	32.4%	48.3%	80.7%
EC-30B5	30	45	4BTA3.9-G	37	4.L	3.9	32.5%	48.4%	80.9%
EC-50B5	50	74	6BTA5.9-G	80	6.L	5.9	32.7%	48.8%	81.5%
EC-60B5	60	90	6BTA5.9-G	80	6.L	5.9	32.8%	48.9%	81.7%
EC-80B5	80	117	6CTA8.3-G	125	6.L	8.3	33.4%	49.1%	82.5%
EC-100B5	100	148	6CTA8.3-G	125	6.L	8.3	33.5%	49.3%	82.8%
EC-160B5	160	217	NTA855-G	210	6.L	14	35.3%	48.1%	83.4%
EC-180B5	180	247	NTA855-G	210	6.L	14	35.4%	48.3%	83.7%
EC-250B5	250	310	KTA19-G	330	6.L	19	38.0%	47.2%	85.2%
EC-280B5	280	348	KTA19-G	330	6.L	19	38.1%	47.3%	85.4%
EC-450B5	450	558	KTA38-G	550	12.V	38	38.1%	47.3%	85.4%
EC-500B5	500	620	KTA38-G	550	12.V	38	38.3%	47.5%	85.8%



Remarks:

• Above Gensets are based on 50Hz, 1500rpm, 400V, 3 Phases & 4 Wires.

• According to ISO3046 at U=0.4kV, cosphi=1.0 for 50Hz, methane number of Biogas＞100, lower calorific value: LHV>6kWh/Nm³.

• Electrical efficiency is based on cosphi =1.0 and ISO3046 conditions. Heat is recovered from jacket water and exhaust gas cooled to 180℃.

• Operations conditions is based on ambient temperature -25-25℃ and altitude less than 1000m.

• For power deratings caused by other temps and altitudes, please consult Ettes Power.

• Other low voltages and high voltage of 3.3kV, 6.3kV and 10.5kV are available for options.

• Models with "B" for Biogas (Sewage Gas, Wastewater Gas, Landfill Gas, Farm Gas, Digester Gas, Manure Gas, Agricultural gas etc).

• Special configurations for Soundproof Canopy & Container, ATS and Synchronizing Parallel System are available for options.

• Special configuration of CHP, CCHP (trigeneration), Cogeneration are available for options.

• All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.



Model List of Cummins Biogas Gensets & CHPs (60Hz, 1800rpm)
Model	Elec. Power (kWe)	Heat Output (kWt)	Engine Model	Engine Max Power (kW)	Cyls. & Type	Dspl.(L)	Elec. Eff.	Heat Eff.	Total Eff.	PDF D/L
EC-24B6	24	35	4BTA3.9-G	37	4.L	3.9	32.4%	48.3%	80.7%
EC-30B6	30	45	4BTA3.9-G	37	4.L	3.9	32.5%	48.4%	80.9%
EC-50B6	50	74	6BTA5.9-G	80	6.L	5.9	32.7%	48.8%	81.5%
EC-60B6	60	90	6BTA5.9-G	80	6.L	5.9	32.8%	48.9%	81.7%
EC-80B6	80	117	6CTA8.3-G	125	6.L	8.3	33.4%	49.1%	82.5%
EC-100B6	100	148	6CTA8.3-G	125	6.L	8.3	33.5%	49.3%	82.8%
EC-160B6	160	217	NTA855-G	210	6.L	14	35.3%	48.1%	83.4%
EC-180B6	180	247	NTA855-G	210	6.L	14	35.4%	48.3%	83.7%
EC-250B6	250	310	KTA19-G	330	6.L	19	38.0%	47.2%	85.2%
EC-280B6	280	348	KTA19-G	330	6.L	19	38.1%	47.3%	85.4%
EC-450B6	450	558	KTA38-G	550	12.V	38	38.1%	47.3%	85.4%
EC-500B6	500	620	KTA38-G	550	12.V	38	38.3%	47.5%	85.8%



• Above Gensets are based on 60Hz, 1800rpm, 480V, 3 Phases & 4 Wires.

• According to ISO3046 at U=0.4kV, cosphi=1.0 for 60Hz, methane number of Biogas＞100, lower calorific value: LHV>6kWh/Nm³.

• Electrical efficiency is based on cosphi =1.0 and ISO3046 conditions. Heat is recovered from jacket water and exhaust gas cooled to 180℃.

• Operations conditions is based on ambient temperature -25-25℃ and altitude less than 1000m.

• For power deratings caused by other temps and altitudes, please consult Ettes Power.

• Other low voltages and high voltage of 3.3kV, 6.3kV and 10.5kV are available for options.

• Models with "B" for Biogas (Sewage Gas, Wastewater Gas, Landfill Gas, Farm Gas, Digester Gas, Manure Gas, Agricultural gas etc).

• Special configurations for Soundproof Canopy & Container, ATS and Synchronizing Parallel System are available for options.

• Special configuration of CHP, CCHP (trigeneration), Cogeneration are available for options.

• All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.

At power scope of 60~560kW, Ettes MAN series biogas generator & CCHP (combined cooling heat and power) are driven by engines of E0834, E0836, E2848, E2876, E2676, E3268 and E3262, with merits of compact design, high electrical and thermal efficiency, low consumption of gas fuel and lub oil, extended service intervals of over 50000 hours and low emissions due to state-of-the-art combustion technologies etc. MAN Series biogas engine generator cogeneration & trigeneration units are the ideal solutions for biogas power plant, biogas distributed energy resource system (DER) and other WtE (waste to energy) projects.



Models List of MAN Biogas Gensets & CHPs (50Hz, 1500rpm)
Model	Elec. Power (kWe)	Heat Output (kWt)	Engine Model	Engine Power (kW)	Cyls. & Type	Dspl. (L)	Elec. Eff.	Heat Eff.	Total Eff.	PDF D/L
EM-66B5	66	93	E0834LE302	68	4.L	4.6	36.5%	45.0%	81.5%
EM-100B5	100	135	E0836LE302	110	6.L	6.9	37.8%	45.0%	82.8%
※EM-130B5	130	/	E2876TE302	130	6.L	12.8	36.5%	/	/
☆EM-200B5	200	/	E2876LE202	220	6.L	12.8	36.7%	/	/
★EM-200B5	200	255	E2876LE302	200	6.L	12.8	36.7%	46.8%	83.5%
EM-220B5	220	269	E2676LE212	220	6.L	12.8	40.2%	49.1%	89.3%
※EM-300B5	300	379	E3268LE252	320	8.V	17.2	39.2%	49.5%	88.7%
EM-350B5	350	450	E3268LE222	370	8.V	17.2	39.3%	50.5%	89.8%
EM-430B5	430	481	E3262LE242	450	12.V	25.8	39.3%	43.0%	82.3%
EM-520B5	520	654	E3262LE212	550	12.V	25.8	38.3%	48.2%	86.5%
EP-1000B5	1000	1090	4016-60TRS2	1042	16.V	61.1	38.7%	42.2%	80.9%



Remarks:

• Above Gensets are based on 50Hz, 1500rpm, 400V, 3 Phases & 4 Wires.

• According to ISO3046 at U=0.4kV, cosphi=1.0 for 50Hz, methane number of Biogas＞100, lower calorific value: LHV>6kWh/Nm³.

• Electrical efficiency is based on cosphi =1.0 and ISO3046 conditions. Heat is recovered from jacket water and exhaust gas cooled to 150℃.

• Operations conditions is based on ambient temperature -25-25℃ and altitude less than 500m.

• For power deratings caused by other temps and altitudes, please consult Ettes Power.

• Other low voltages and high voltage of 3.3kV, 6.3kV and 10.5kV are available for options.

• Models with "B" for Biogas (Sewage Gas, Wastewater Gas, Landfill Gas, Farm Gas, Digester Gas, Manure Gas, Agricultural gas etc).

• Models with "☆" for only power generation units; Models with "★" for only CHP(combined power and heat) units.

• Special configurations for Soundproof Canopy & Container, ATS and Synchronizing Parallel System are available for options.

• Special configuration of CHP, CCHP (trigeneration), Cogeneration are available for options.

• All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.



Models List of MAN Biogas Gensets & CHPs (60Hz, 1800rpm)
Model	Elec. Power (kWe)	Heat Output (kWt)	Engine Model	Engine Power (kW)	Cyls. & Type	Dspl. (L)	Elec. Eff.	Heat Eff.	Total Eff.	PDF D/L
EM-66B6	66	93	E0834LE302	68	4.L	4.6	36.5%	45.0%	81.5%
EM-100B6	100	135	E0836LE302	110	6.L	6.9	37.8%	45.0%	82.8%
EM-200B6	200	242	E2876LE302	200	6.L	12.8	36.7%	46.8%	83.5%
EM-220B6	220	269	E2676LE212	250	6.L	12.8	40.2%	49.1%	89.3%
※EM-320B6	320	402	E3268LE252	340	8.V	17.2	39.2%	49.3%	88.5%
EM-350B6	350	450	E3268LE222	390	8.V	17.2	39.3%	50.5%	89.8%
※EM-360B6	360	525	E3268LE222	390	8.V	17.2	37.5%	50.5%	87.5%
EM-430B6	430	481	E3262LE242	450	12.V	25.8	39.3%	43.0%	82.3%
EM-520B6	520	654	E3262LE212	580	12.V	25.8	40.0%	43.0%	83.0%
EM-560B6	560	716	E3262LE212	580	12.V	25.8	40.0%	46.5%	86.5%



Remarks:

• Above Gensets are based on 60Hz/1800rpm, 480V,3 Phases & 4 Wires.

• According to ISO3046 at U=0.48kV, cosphi=1.0 for 60Hz, methane number of Biogas＞100, lower calorific value: LHV>6kWh/Nm³.

• Electrical efficiency is based on cosphi =1.0 and ISO3046 conditions. Heat is recovered from jacket water and exhaust gas cooled to 150℃.

• Operations conditions is based on ambient temperature -25-25℃ and altitude less than 500m.

• For power deratings caused by other temps and altitudes, please consult Ettes Power.

• Other low voltages and high voltage of 4.16kV, 6.6kV and 13.8kV are available for options.

• Models with "B" for Biogas (Sewage Gas, Wastewater Gas, Landfill Gas, Farm Gas, Digester Gas, Manure Gas, Agricultural gas etc).

• Special configurations for Soundproof Canopy & Container, ATS and Synchronizing Parallel System are available for options.

• Special configuration of CHP, CCHP (trigeneration), Cogeneration are available for options.

• All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.



At power scope of 400kW~2000kW, Ettes Cat-MWM series biogas power generation & CCHP (combined cooling heat and power) system are driven by engines of TCG3016 (CG132), TCG2020 (CG170) and TCG2032 (CG260) at cylinder config. of V8, V12, V16 and V20, with benefits of most compact design, highest optimized electrical efficiency (over 40%~43.7%), lowest consumption of gas fuel and lub oil, longest overhaul time over 64000 hours and low emissions levels due to advanced combustion technologies etc. MWM Series biogas power generation, CHP(combined heat and power) units and cogenerations can be called the best solutions for biogas generating set , biogas power stations and heat recovery application all over the world.



Models List of MWM Biogas Gensets & CHP (50Hz, 1500rpm)
Model	Elec. Power (kWe)	Heat Output (kWt)	Engine Model	Engine Power (kW)	Cyls.& Type	Dspl. (L)	Elec Eff.	Heat Eff.	Total Eff.	PDF D/L
※EW-400B5	400	394	TCG3016V8/CG132-8	436	8.V	17.5	42.8%	42.2%	85.0%
EW-600B5	600	599	TCG3016V12/CG132-12	656	12.V	26.3	42.9%	42.8%	85.7%
EW-800B5	800	791	TCG3016V16/CG132-16	820	16.V	35.0	43.1%	42.6%	85.7%
EW-1000B5	1000	1037	TCG2020V12/CG170-12	1187	12.V	53.1	42.6%	44.2%	86.8%
EW-1200B5	1200	1194	TCG2020V12/CG170-12	1245	12.V	53.1	43.0%	42.8%	85.8%
EW-1560B5	1560	1577	TCG2020V16/CG170-16	1620	16.V	70.8	42.6%	43.1%	85.7%
EW-2000B5	2000	2012	TCG2020V20/CG170-20	2079	20.V	88.5	43.6%	42.9%	86.5%



Remarks:

• Above Gensets are based on 50Hz, 1500rpm, 400V, 3 Phases & 4 Wires.

• According to ISO3046 at U=0.4kV, cosφ=1.0 for 50Hz, methane number of Biogas＞134(sewage gas), lower calorific value: LHV>5kWh/Nm³.

• Elec. efficiency is based on cosφ=1.0 & ISO3046. Heat recovered from jacket water & exhaust cooled to 150℃ (TCG 3016)/180℃ (TCG 2020).

• Operations conditions is based on ambient temperature -25-25℃ and altitude less than 1000m.

• For power deratings caused by other temps and altitudes, please consult Ettes Power.

• Other low voltages and high voltage of 3.3kV, 6.3kV and 10.5kV are available for options.

• Models with "B" for Biogas (Sewage Gas, Wastewater Gas, Landfill Gas, Farm Gas, Digester Gas, Manure Gas, Agricultural gas etc).

• Special configurations for Soundproof Container, ATS and Synchronizing Parallel System are available for options.

• Special configuration of CHP, CCHP (trigeneration), Cogeneration are available for options.

• All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.



Models List of MWM Biogas Gensets & CHP (60Hz, 1800rpm)
Model	Elec. Power (kWe)	Heat Output (kWt)	Engine Model	Engine Power (kW)	Cyls.& Type	Dspl. (L)	Elec Eff.	Heat Eff.	Total Eff.	PDF D/L
※EW-400B6	400	414	TCG3016V8/CG132-8	436	8.V	17.5	42.8%	42.2%	85.0%
EW-600B6	600	627	TCG3016V12/CG132-12	656	12.V	26.3	41.7%	43.6%	85.3%
EW-800B6	800	827	TCG3016V16/CG132-16	820	16.V	35	41.9%	43.3%	85.2%
EW-1200B6	1200	1200	TCG2020V12/CG170-12	1245	12.V	53.1	42.8%	42.8%	85.6%
EW-1560B6	1560	1588	TCG2020V16/CG170-16	1620	16.V	70.8	42.3%	43.1%	85.4%
EW-2000B6	2000	2088	TCG2020V20/CG170-20	2079	20.V	88.5	42.6%	43.1%	85.7%



Remarks:

• Above Gensets are based on 60Hz, 1800rpm, 480V,3 Phases & 4 Wires.

• According to ISO3046 at U=0.48kV, cosphi=1.0 for 60Hz, methane number of Biogas＞134(sewage gas), lower calorific value: LHV>5kWh/Nm³.

• Electrical efficiency is based on cosphi =1.0 and ISO3046 conditions. Heat is recovered from jacket water and exhaust gas cooled to 150℃ (TCG 3016)/180℃ (TCG 2020).

• Operations conditions is based on ambient temperature -25-25℃ and altitude less than 1000m.

• For power deratings caused by other temps and altitudes, please consult Ettes Power.

• Other low voltages and high voltage of 4.16kV, 6.6kV and 13.8kV are available for options.

• Models with "B" for Biogas (Sewage Gas, Wastewater Gas, Landfill Gas, Farm Gas, Digester Gas, Manure Gas, Agricultural gas etc).

• Special configurations for Soundproof Container, ATS and Synchronizing Parallel System are available for options.

• Special configuration of CHP, CCHP (trigeneration), Cogeneration are available for options.

• All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.
