CNPC Natural Gas Generators

Ettes Power CNPC series natural gas engine generator & CCHPs, range from 300kW to 2MW, high quality & performance in gas power generation plant in fields under harsh working conditions.
  • CNPC Natural Gas Power Package

  • ETTES POWER

  • EJN Natural Gas Congeneration Series Natural Gas Series,300kW, 500kW, 600kW, 700kW, 1000kW(1MW)and 2000kW(2MW).

Availability:

ETTESPOWER-CNPC-GAS-ENGINE-GENERATOR-SET-CHP-500KW-1000KW-1MW-ETTES-POWER


► About CNPC Engines

CNPC Series gas engines are developed by cooperation with AVL from Germany and Austria. The engine assembling plant is affiliated to CNPC (China National Petroleum & Oil Corporation), which is the first and the largest engine manufacture in China since 1953. CNPC engine generator performance is “Leading China” and “First class Global”, which work widely in 80% of China Oil & Gas Fields, Coalmines, Vessels and other areas under harsh working conditions, enjoy high reputation in global.


► About Ettes-CNPC Gas Engine Generators

400kW~1200kW, Powerful, Big Displacement, Strong loads-starting-ability, Long Serice Life

Ettes CNPC series gas fired generators & CHPs are driven by engines series of 6140, 12V190, G12V190 and H16V190 etc, with merits of big displacement, sufficient reserve-power, strong capability against loads-surge, easy for installation & maintenance, long overhaul, widely used in oil & gas fields, coalmines and wild construction etc. It is the ideal solution for electrical generation to drive loads under harsh conditions for island operation.


Besides standard package of electrical generator, Ettes can satisfy client’s special requirements and make tailored design like CHP, CCHP/Trigeneration, Cogeneration, ATS, Parallel operation system, Remote monitor & Control, Modularized soundproof & weatherproof container, which can realize the most efficient and comprehensive use of energy and generate electricity, hot water, cooled water, hot steam or hot oil etc.


Ettes Power 500kw 1000kw 1mw 2mw gas engine power palnt station Ettespower


► Customer Benefits for CNPC Gas Power Generation

  The engine performance is “Leading China” and “First class Global”

  Long history: produced by engines plant under control by CNPC (China National Petroleum & Oil Corporation), it is the first and the largest engine manufacture in China since 1953.

  Proven Technology: widely used in 80% of China Oil & Gas Fields and Coalmines under harsh working conditions.

  Fuel flexibility: a wide range of methane based gases including natural gas and biogas etc.

  Designed for intensive use (continuous duty), able to act as main power supply or standby power supply.

  Capable of working with variable loads, strong capability of against loads-surge.

  Advanced technology of close-loop control, lean-burn and Mixing before turbo.

  Adopting highly intelligent gas control system of USA Woodward EGS, Germany Heinzmann or Motortech, the air fuel ratio can be automatically adjusted as per fluctuation of gas components.

  Adopting intelligent & digital ignition system from Germany Motortech or USA Altronic.

  Adopting super-turbocharged technology from ABB.

  Heat Recovery system to realize CHP, Cogeneration and Distribution Energy.

  Integrated & modularized unit to facilitate easy transport and quick setup.

  Easy Maintenance in low operations cost due to enchanced materials adopted.

  Ensured annually continuous working over 8000 hours and long engine-life-span of over 45000 hours.

  Service and Spare parts are widely and easily available, supplied by service center ETTES POWER.

Ettespower CNPC Gas Power Range of CNPC Gas Generation Ettes Power

  All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.


► About Production Standards & Certification

 Prevailing Industry Standards: ISO3046,ISO8528,GB2820, BS5000PT99,AS1359,IEC34, DIN6271, BS5514.

 ISO Standards: ISO9001:2008, ISO14001, ISO45001 (former OHSAS 18001)

• National & Regional Comformity Standards: CE, UL, EPA, CSA and SONCAP etc.

 Third Party Certification for Gensets: SGS, CCS, BV, ABS and DNV-GL etc.


► Adoped Wolrd Top Materials to Assemble Generator Set

 Gas Engines Brands: Cummins, MAN, MWM, CNPC

 Alternators Brands: Stamford AVK, Leroy Somer, Marelli, or Mec calte

 Control System: Deepsea, ComAp or DEIF

 Air Circuit Breaker/Switchgear: ABB, Schneider, Eaton or Siemens

 Governing Actuator: Germany Mototerch, Heinzmann, USA Woodward or Swiss Huegli

 Air-Gas Mixer: Auto, Electrically controlled, Germany Motortech or Swiss Huegli

 Ignition System: Germany Mototerch, USA Altronic or Swiss Huegli

• Key Materials of CHP System: Siemens, Alfa laval, Swep and Grundfos

 Gas Train (safty valves): Germany Dungs, Chroms or Italy Madas

 Tailored configuration: Common soundproof canopy, 20 & 40 feet modular container, ATS/ACS system, Synchronization parallel panel, Remote control & Scada system, Oil & cylinder water heater, Anti-condensation heater (space heater), Digital AVR, AREP/PMG system, IP44 protection level & B class temperature rise, High voltage alternator (3.3kV, 6.3kV, 10.5kV etc.), CHP, CCHP, and Trigeneration etc.


► Applicable Gas Fuels & Quality Requirements

• Pipeline Natural Gas (PNG, CNG, LNG)

 Oilfield APG (Associated Petroleum Gas)

 Coalmine Methane Gas

• CBM (Coalbed Methane)

 Well Gas, Shale Gas & Other Methane Based Gases

 Gas Fuel Quality Requirements


Composition Abbr. Limits Remarks
Methane number MN >80 for natural gas For Lower value, please consult ETTES POWER
Calorific value Hμ,N Lower value of 36MJ/Nm³ Standard Calorific Value for Ettes Datasheet as per
ISO8528/1, ISO3046/1 and BS5514/1.
Chlorine CL <80 mg / Nm³ CH4

For higher value, please consult ETTES POWER

Fluoride F <40 mg / Nm³ CH4 For higher value, please consult ETTES POWER
Total-chlorine Fluoride ∑(Cl,F) <80 mg / Nm³ CH4 For higher value, please consult ETTES POWER
Dust / <5μm
<10 mg / Nm³ CH4
For higher value, please consult ETTES POWER
Oil Vapor  / <400 mg / Nm³ CH4 No condensation may occur in the mixture section
Silicon Element Si <2 mg / Nm³ CH4 For higher value, please consult ETTES POWER
Sulphur S <200 mg / Nm³ For higher values, please consult ETTES POWER
Hydrogen Sulphide H2S <150 ppm or <228 mg / Nm³ For higher value, please consult ETTES POWER
Ammonia NH3 <40 ppm or<30 mg / Nm³ For other values, please consult ETTES POWER
Gas Pressure Range / 100kPa~400kPa For other values, please consult ETTES POWER
Gas Temperature / <30℃ For other values, please consult ETTES POWER




► Typical Diagram of Ettes CNPC Series Gas Generator CHP

Ettes Power Gas Engine Generators CHPs running diagram Ettespower Group



► Typical Application Fields

Application-Fields-of-Ettes-Power-Natural-Gas


Models List of CNPC Natural Gas Gensets & CHPs (50Hz, 1000rpm)

Model Elec. Power (kWe) Heat Output (kWt) Engine Model Engine Power (kW) Cyls. & Type Dspl.(L) Elec. Eff.  Heat Eff. Total Eff.

PDF

D/L

EJ-300N5 300
375 JC15DT 350 6.L 15 37.2% 46.5% 83.1% click download pdf
EJ-500N5 500 627 12V190ZDT 600 12.V 71 36.1% 45.3% 81.4% click download pdf
EJ-600N5 600 770 12V190ZL 660 12.V 71 37.0% 47.5% 84.5% click download pdf
EJ-700N5 700 903 12V190ZL 750 12.V 71 37.2% 48.0% 85.2% click download pdf
EJ-1200N5 1200 1416 H16V190ZLT 1320 16.V 97 38.3% 45.2% 83.5% click download pdf
EJ-2000N5 2000 2258 L20V190ZLT 2200 20.V 145 40.2% 45.4% 85.6% click download pdf

Remarks:

• Above Gensets are based on 50Hz, 1000rpm, 400V, 3 Phases & 4 Wires.

• According to ISO3046-1 at U=0.4kV, cosphi=1.0 for 50Hz, methane number of natural gas80, lower calorific value: LHV>36MJ/Nm³.

• Electrical efficiency is based on cosphi =1.0 and ISO3046 conditions. Heat is recovered from jacket water and exhaust gas cooled to 120.

• Operations conditions is based on ambient temperature -25-25 and altitude less than 1000m.

• For power deratings caused by other temps and altitudes, please consult Ettes Power.

• Other low voltages and high voltage of 3.3kV, 6.3kV and 10.5kV are available for options.

• Models with "N" for Natural gas (CNG, PNG, LNG, Shale Gas, Oilfield Associated Gas and Coalmine Gas etc).

• Special configurations for Soundproof Canopy & Container, ATS and Synchronizing Parallel System are available for options.

• Special configuration of CHP, CCHP (trigeneration), Cogeneration are available for options.

• All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.

Models List of CNPC Natural Gas Gensets & CHPs (60Hz, 1200rpm)

Model Elec. Power (kWe) Heat Output (kWt) Engine Model Engine Power (kW) Cyls. & Type Dspl.(L) Elec. Eff.  Heat Eff. Total Eff.

PDF

D/L

EJ-300N6 300
375 JC15DT 350 6.L 15 37.2% 46.5% 83.1% click download pdf
EJ-500N6 500 627 12V190ZDT 600 12.V 71 36.1% 45.3% 81.4% click download pdf
EJ-600N6 600 770 12V190ZL 660 12.V 71 37.0% 47.5% 84.5% click download pdf
EJ-700N6 700 903 12V190ZL 750 12.V 71 37.2% 48.0% 85.2% click download pdf
EJ-1200N6 1200 1416 H16V190ZLT 1320 16.V 97 38.3% 45.2% 83.5% click download pdf
EJ-2000N6 2000 2258 L20V190ZLT 2200 20.V 145 40.2% 45.4% 85.6% click download pdf

Remarks:

• Above Gensets are based on 60Hz, 1200rpm, 480V, 3 Phases & 4 Wires.

• According to ISO3046-1 at U=0.48kV, cosphi=1.0 for 60Hz, methane number of natural gas80, lower calorific value: LHV>36MJ/Nm³.

• Electrical efficiency is based on cosphi =1.0 and ISO3046 conditions. Heat is recovered from jacket water and exhaust gas cooled to 120.

• Operations conditions is based on ambient temperature -25-25 and altitude less than 1000m.

• For power deratings caused by other temps and altitudes, please consult Ettes Power.

• Other low voltages and high voltage of 4.16kV, 6.6kV and 13.8kV are available for options.

• Models with "N" for Natural gas (CNG, PNG, LNG, Shale Gas, Oilfield Associated Gas and Coalmine Gas etc).

• Special configurations for Soundproof Canopy & Container, ATS and Synchronizing Parallel System are available for options.

• Special configuration of CHP, CCHP (trigeneration), Cogeneration are available for options.

• All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.
