Cummins Series Biogas Generator Set

Name: Cummins Series Biogas Generator Set
Brand: ETTES POWER
Rating: 5.0 (43 reviews)

Ettes Power Cummins series biogas engine generator & CCHPs, from 30kW to 500kW, high performance & high efficiency for project of cogenerator of WtE (waste to energy) & distributed energy system.

Model:
Cummins Biogas Power Package
Brand:
ETTES POWER
Code:
ECB Biogas Cogeneration Series, 30kW,50kW, 60kW, 80kW,100kW,150kW, 180kW, 200KW,250kW,280kW, 300kW,450kW and 500kW.

Availability:



Inquire

► About Cummins Engines global

Cummins is one of world top engines brands and widely acceptable all over the world. Cummins Inc., a global power leader, a corporation of complementary business units that design, manufacture, distribute and service engines and related technologies, including fuel systems, controls, air handling, filtration, emission solutions and electrical power generating set. Headquartered in Columbus, Indiana, (USA) Cummins serves customers in approximately 190 countries and territories through a network of more than 600 company-owned and independent distributor locations and approximately 5,200 dealer locations. For details, please click here to read more.

► About Cummins Gas Engine Generators

30kW~500kW, Reliable, Clean, Quiet, Powerful

As a leading manufacturer and packager for complete generator set, Ettes biogas engine generators & CCHPs & Cogenerations power ranging from 30kW upto 500kW, which enjoy hot markets and high reputation in over 70 countries & regions all over the world including Latin America, Africa, South-eastern Asia, Middle East and Europe etc.

Ettes Cummins series biogas generators & CHPs are driven by engines series of 4B3.9, 6B5.9, 6C8.3, NT855, KT19 and KT38 etc, with merits of high reliable, quick installation, easy operation and low maintenance cost. Besides standard package of gas fired generator, client’s special requirements can be tailored such as CHP(combined heat and power), Cogeneration, trigeneration ,combined cold heat and power (CCHP), ATS, Parallel operation system, Remote monitor & Control, Modularized soundproof & weatherproof container. Ettes biogas engine generator & CHPs are the ideal solutions for project of waste to energy, the suitable fuel can be methane based biogas like agricultural farm gas, sewage gas, landfill gas and other types of digester gas fuels etc.

► Customer Benefits for Cummins Gas Power Generation

• The engine brand is globally recognized and the performance is highly reliable.

• Proven Technology: widely used in various industries and fields under harsh working conditions.

• Fuel flexibility: applicable for a wide range of methane based gases like natural gas, biogas and oilfield gas etc.

• Designed for intensive use (continuous duty), able to act as main power generator supply or standby fueled generator supply.

• Applicable for both island mode and parallel with mains grid, strong capability of working with variable loads.

• Advanced technology of lean-burn, simple for commissioning, operations and maintenance.

• Adopting highly intelligent gas control system, top brands of Germany Motortech, USA Altronic and Swiss Huegli etc.

• Heat Recovery system to realize CHP, Cogeneration and Distribution Energy.

• Low emissions of NOx and CO of environmental friendly, can satisfy strict requirements by three way catalyst or SCR.

• Integrated & modularized unit to facilitate easy transport and quick setup.

• Spare parts are vastly and easily available all over the world, smooth maintenance in Low Cost.

• Strong warranty & Guarantee Policy: for each Ettes power gas engine generator, Ettes supply one year warranty, life-span technical support & spare parts at manufacture price. Furthermore, all Cummins engine are covered by global-united warranty and distributor service network.

• Power ranging from 30kW upto 1000kW.

Ettespower Cummins Natural gas Biogas Power Range of Ettes Power

All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.

► About Production Standards & Certification

• Prevailing Industry Standards: ISO3046，ISO8528，GB2820, BS5000PT99,AS1359,IEC34, DIN6271, BS5514.

• ISO Standards: ISO9001:2008, ISO14001, ISO45001 (former OHSAS 18001)

• National & Regional Conformity Standards: CE, UL, EPA, CSA and SONCAP etc.

• Third Party Certification for Gensets: SGS, CCS, BV, ABS and DNV-GL etc.

► Adopted World Top Materials to Assemble Gas Generating Set

• Gas Engines Brands: Cummins, MAN, MWM, CNPC

• Alternators Brands: Stamford AVK, Leroy Somer, Marelli, or Mec calte

• Control System: Deepsea, ComAp or DEIF

• Air Circuit Breaker/Switchgear: ABB, Schneider, Eaton or Siemens

• Governing Actuator: Germany Mototerch, Heinzmann, USA Woodward or Swiss Huegli

• Air-Gas Mixer: Auto, Electrically controlled, Germany Motortech or Swiss Huegli

• Ignition System: Germany Mototerch, USA Altronic or Swiss Huegli

• Key Materials of CHP System: Siemens, Alfa laval, Swep and Grundfos

• Gas Train (safty valves): Germany Dungs, Chroms or Italy Madas

• Tailored configuration: Common soundproof canopy, 20 & 40 feet modular container, ATS/ACS system, Synchronization parallel panel, Remote control & Scada system, Oil & cylinder water heater, Anti-condensation heater (space heater), Digital AVR, AREP/PMG system, IP44 protection level & B class temperature rise, High voltage alternator (3.3kV, 6.3kV, 10.5kV etc.), CHP, CCHP, and Trigeneration etc.

► Applicable Gas Fuels & Quality Requirements

• Farms Digester Biogas

• Agricultural Straw Biogas

• LFG (landfill biogas)

• Sewage Biogas (Waste Water)

• Other Methane Based Biogas

Ettes Power Biogas Production Plant Digester gas generator-Ettespower

Composition	Abbr.	Limits	Remarks
Methane number	MN	＞100 for biogas	For Lower value, please consult ETTES POWER
Calorific value	Hμ，N	Lower value of 6kw.h/Nm³	Standard Calorific Value for Ettes Datasheet as per ISO8528/1, ISO3046/1 and BS5514/1.
Chlorine	CL	＜80 mg / Nm³ CH4	For higher value, please consult ETTES POWER
Fluoride	F	＜40 mg / Nm³ CH4	For higher value, please consult ETTES POWER
Total-chlorine Fluoride	∑(Cl,F)	＜80 mg / Nm³ CH4	For higher value, please consult ETTES POWER
Dust	/	＜5μm ＜10 mg / Nm³ CH4	For higher value, please consult ETTES POWER
Oil Vapor	/	＜400 mg / Nm³ CH4	No condensation may occur in the mixture section
Silicon Element	Si	＜2 mg / Nm³ CH4	For higher value, please consult ETTES POWER
Sulphur	S	＜200 mg / Nm³	For higher values, please consult ETTES POWER
Hydrogen Sulphide	H2S	＜150 ppm or ＜228 mg / Nm³	For higher value, please consult ETTES POWER
Ammonia	NH3	＜40 ppm or＜30 mg / Nm³	For other values, please consult ETTES POWER
Gas Pressure Range	/	5kPa~20kPa	For other values, please consult ETTES POWER
Gas Temperature	/	＜30℃	For other values, please consult ETTES POWER

► Typical Diagram of Ettes Cummins Series Gas Generator CHP

Ettes Power Diagram of Biogas Sewage gas landfill gas engine generators CHPs Ettespower

► Typical Application Fields

Application-Fields-of-Ettes-Power-Gas-Engine-Generator

Model List of Cummins Biogas Gensets & CHPs (50Hz, 1500rpm)
Model	Elec. Power (kWe)	Heat Output (kWt)	Engine Model	Engine MaxPower (kW)	Cyls. & Type	Dspl.(L)	Elec. Eff.	Heat Eff.	Total Eff.	PDF D/L
EC-24B5	24	35	4BTA3.9-G	37	4.L	3.9	32.4%	48.3%	80.7%
EC-30B5	30	45	4BTA3.9-G	37	4.L	3.9	32.5%	48.4%	80.9%
EC-50B5	50	74	6BTA5.9-G	80	6.L	5.9	32.7%	48.8%	81.5%
EC-60B5	60	90	6BTA5.9-G	80	6.L	5.9	32.8%	48.9%	81.7%
EC-80B5	80	117	6CTA8.3-G	125	6.L	8.3	33.4%	49.1%	82.5%
EC-100B5	100	148	6CTA8.3-G	125	6.L	8.3	33.5%	49.3%	82.8%
EC-160B5	160	217	NTA855-G	210	6.L	14	35.3%	48.1%	83.4%
EC-180B5	180	247	NTA855-G	210	6.L	14	35.4%	48.3%	83.7%
EC-250B5	250	310	KTA19-G	330	6.L	19	38.0%	47.2%	85.2%
EC-280B5	280	348	KTA19-G	330	6.L	19	38.0%	47.3%	85.3%
EC-450B5	450	558	KTA38-G	550	12.V	38	38.2%	47.3%	85.5%
EC-500B5	500	620	KTA38-G	550	12.V	38	38.3%	47.5%	85.8%

Remarks:

• Above Gensets are based on 50Hz, 1500rpm, 400V, 3 Phases & 4 Wires.

• According to ISO3046 at U=0.4kV, cosphi=1.0 for 50Hz, methane number of Biogas＞100, lower calorific value: LHV>6kWh/Nm³.

• Electrical efficiency is based on cosphi =1.0 and ISO3046 conditions. Heat is recovered from jacket water and exhaust gas cooled to 180℃.

• Operations conditions is based on ambient temperature -25-25℃ and altitude less than 1000m.

• For power deratings caused by other temps and altitudes, please consult Ettes Power.

• Other low voltages and high voltage of 3.3kV, 6.3kV and 10.5kV are available for options.

• Models with "B" for Biogas (Sewage Gas, Wastewater Gas, Landfill Gas, Farm Gas, Digester Gas, Manure Gas, Agricultural gas etc).

• Special configurations for Soundproof Canopy & Container, ATS and Synchronizing Parallel System are available for options.

• Special configuration of CHP, CCHP (trigeneration), Cogeneration are available for options.

• All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.

Model List of Cummins Biogas Gensets & CHPs (60Hz, 1800rpm)
Model	Elec. Power (kWe)	Heat Output (kWt)	Engine Model	Engine Max Power (kW)	Cyls. & Type	Dspl.(L)	Elec. Eff.	Heat Eff.	Total Eff.	PDF D/L
EC-24B6	24	35	4BTA3.9-G	37	4.L	3.9	32.4%	48.3%	80.7%
EC-30B6	30	45	4BTA3.9-G	37	4.L	3.9	32.5%	48.4%	80.9%
EC-50B6	50	74	6BTA5.9-G	80	6.L	5.9	32.7%	48.8%	81.5%
EC-60B6	60	90	6BTA5.9-G	80	6.L	5.9	32.8%	48.9%	81.7%
EC-80B6	80	117	6CTA8.3-G	125	6.L	8.3	33.4%	49.1%	82.5%
EC-100B6	100	148	6CTA8.3-G	125	6.L	8.3	33.5%	49.3%	82.8%
EC-160B6	160	217	NTA855-G	210	6.L	14	35.3%	48.1%	83.4%
EC-180B6	180	247	NTA855-G	210	6.L	14	35.4%	48.3%	83.7%
EC-250B6	250	310	KTA19-G	330	6.L	19	38.0%	47.2%	85.2%
EC-280B6	280	348	KTA19-G	330	6.L	19	38.0%	47.3%	85.3%
EC-450B6	450	558	KTA38-G	550	12.V	38	38.2%	47.3%	85.5%
EC-500B6	500	620	KTA38-G	550	12.V	38	38.3%	47.5%	85.8%

Remarks:

• Above Gensets are based on 60Hz, 1800rpm, 480V, 3 Phases & 4 Wires.

• According to ISO3046 at U=0.4kV, cosphi=1.0 for 60Hz, methane number of Biogas＞100, lower calorific value: LHV>6kWh/Nm³.
