EMM Gensets Models List

Ettespower MAN Marine Series diesel generator set, from 400kW to 2000kW, with merits of Reliable, Clean, Quiet and Powerful, which can be certified by CCS, BV, ABS and DNV-GL.
  • MAN Marine Power Package

  • Ettes Power

  • EMM Marine Series

Availability:


Ettes-power-MAN-Soundproof-Engine-Diesel-Gas-Generators-Set-100kW-200kW-500kW-EttesPower-Group

Ettes Power Cummins Marine Classification Certifications-Ettespower - 副本


► About MAN Marine Engines


400kW~2000kW,  Most Optimized Design, Most Fuel-efficient, High Reliable, Low Emissions
As a leading manufacturer and packager for complete marine diesel generator sets, Ettes marine generations are driven by world top engines brands of Cummins, MWM-Deutz and MAN seris, coupled with alternators of Leroy Somer, Stamford, Siemens and ABB series etc, which enjoy hot markets and high reputation in more than 70 countries all over the world.


Ettes MAN series marine auxiliary generators driven by medium speed engines of L16/24 and L21/31 Series based on cylinders number of 5, 6, 7, 8 and 9. As a key product of Ettes Power generators, MAN series marine generations are vastly used in application fields like Cargo ships, Coastguard & patrol boats. Dredging, Ferries, Fishing, Motor boats, Offshore support, Tugs, Yachts and military vessels etc.




► Broadest Range of Fuels

Liquid fuel engines made by MAN Energy Solutions are capable of working with the broadest range of liquid fuels and viscosities. Fossil fuels usable in liquid fuel engines include crude oil, heavy (residual) fuels and distillate diesel oils. Renewable fuels include vegetable oils, animal fats and second-generation bio fuels (such as biomass-to-liquid fuels).




► Ettes Power MAN Marine Diesel Generators


With over 20 years of experience in R & D and manufacturing, Ettes Power supply high quality marine engine generations to global markets. The marine power generator set can be driven by world top marine diesel engines brands of Cummins, Deutz-MWM and MAN Series, coupled with Stamford, Marathon, ABB or Siemens alternators and top control modules of DEIF, CompAp or Woodward etc.

 Power ranging from 400kW upto 2000kW.


 Widely application fields: Ettes brands marine generators have been widely used as main power, marine emergency power for

 Cargo ships     Coastguard & patrol boats     Dredging     Ferries

Fishing     Motor boats    Offshore support    Tugs    Yachts


 Adopted engine series: Ettes mainly use MAN series speed engines of L16/24 and L21/31 Series based on cylinders number of 5, 6, 7, 8 and 9. to fabricate complete marine power station.


 Marine classification society: for Ettes power marine diesel gensets, based on Solid IMO Tier 2 / EPA Tier 3 / EU Stage IIIa and EIAPP, the standard marine certificate is CCS, we also can supply ABS, BV, DNV-GL, ClassNK, LR, RS and KR etc for customer’s options.


 Strong warranty & Guarantee Policy: for each Ettes power marine generation, Ettes supply one year warranty, life-span technical support & spare parts at manufacture price. Furthermore, all MAN engine are covered by global-united warranty and distributor service network.

Shipyards Vessels Ettes Power Marine engine generators applications fields



Models List of MAN HFO/Diesel Marine Gensets (50Hz, 1000rpm)

Model

Rated Power Engine model

Engine Power

 (kW/Hp)

Cyls.&

Type

Dspl.

(liters)

Overall

Dimmension

(mm)

Weight

(kg)

PDF

Download

kW kVa
EM-420M5 420 525 5L 16/24 450/603 5.L 24.0 4151x1390x2354 9500 click download pdf
EM-535M5 535 669 6L 16/24 570/764 6.L 28.8 4516x1390x2354 10500

click download pdf

EM-625M5 625 781 7L 16/24 665/891 7.L 33.6 5086x1390x2354 11400

click download pdf

EM-714M5 714 893 8L 16/24 760/1018 8.L 38.4 5456x1500x2354 12400

click download pdf

EM-803M5 803 1004 9L 16/24 855/1146 9.L 43.2 5731x1500x2369 13100

click download pdf

EM-940M5 940 1175 5L 21/31 1000/1340 5.L 53.5 6607x2115x3183 22500 click download pdf
EM-1240M5 1240 1550 6L 21/31 1320/1769 6.L 64.2 6962x2115x3183 26000 click download pdf
EM-1440M5 1440 1800 7L 21/31 1540/2064 7.L 74.9 7327x2115x3289 29500 click download pdf
EM-1650M5 1650 2063 8L 21/31 1760/2358 8.L 85.6 7682x2115x3289 33000 click download pdf
EM-1860M5 1860 2325 9L 21/31 1980/2653 9.L 96.3 8062x2115x3289 36500 click download pdf

Remarks:

• Above gensets data are based on 50Hz, AC400V, 3 Phases & 3 Wires, Power Factor 0.8.

• Above gensets are with CCS Marine Class as standard, BV, ABS, DNV-GL are optional.

• Above engines emissions standard is based on IMO TIER II and EIAPP.

• Special configurations for Parallel Control, Remote Control and Firefighting system are available for options.

• Above marine engine generators are based on air starting system.

• For MAN marine engines, the suitable fuels can be light diesel or crude oil/HFO.

• All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.






Models List of MAN HFO/Dieses Marine Gensets (60Hz, 1200rpm & 900rpm)

Model

Rated Power Engine model

Engine Power

 (kW/Hp)

Cyls.&

Type

Dspl.

(liters)

Overall

Dimmension

(mm)

Weight

(kg)

PDF

Download

kW kVa
EM-470M5 470 588 5L 16/24 500/670 5.L 24.0 4151x1390x2354 9500 click download pdf
EM-620M5 620 775 6L 16/24 660/884 6.L 28.8 4516x1390x2354 10500

click download pdf

EM-720M5 720 900 7L 16/24 770/1032 7.L 33.6 5086x1390x2354 11400

click download pdf

EM-827M5 827 1034 8L 16/24 880/1179 8.L 38.4 5456x1500x2354 12400

click download pdf

EM-930M5 930 1163 9L 16/24 990/1327 9.L 43.2 5731x1500x2369 13100

click download pdf

EM-940M5 940 1175 5L 21/31 1000/1340 5.L 53.5 6607x2115x3183 22500 click download pdf
EM-1240M5 1240 1550 6L 21/31 1320/1769 6.L 64.2 6962x2115x3183 26000 click download pdf
EM-1440M5 1440 1800 7L 21/31 1540/2064 7.L 74.9 7327x2115x3289 29500 click download pdf
EM-1650M5 1650 2063 8L 21/31 1760/2358 8.L 85.6 7682x2115x3289 33000 click download pdf
EM-1860M5 1860 2325 9L 21/31 1980/2653 9.L 96.3 8062x2115x3289
36500 click download pdf

Remarks:

• Above gensets data are based on 60Hz, AC440V, 3 Phases & 3 Wires, Power Factor 0.8.

• Above gensets are with CCS Marine Class as standard, BV, ABS, DNV-GL are optional.

• Above engines emissions standard is based on IMO TIER II and EIAPP.

• Special configurations for Parallel Control, Remote Control and Firefighting system are available for options.

• Above marine engine generators are based on air starting system.

• For MAN marine engines, the suitable fuels can be light diesel or crude oil/HFO.

• All data provided on this site is for information purposes only, explicitly non-binding and subject to changes without further notice.
